Boat Research

 →

Australia Marine Services

 →

34m AHTS

Australia Marine Services Boats For Sale

 →

Australia Marine Services 34m AHTS

2020 AUSTRALIA MARINE SERVICES AMS TUGS AND BARGES 34M AHTS - New Boat Library

Length
111' 7" - 34.00m
Model Year
2020
Hull Material
Steel

Description: Australia Marine Services AMS Tugs and Barges 34m AHTS
New Build BV 34m x 3200bhp x 41.8T Bollard Pull Unrestricted Offshore Anchor Handler & Towing Tug
The best boat we have ever built. This 34m tug was designed and built to suit Australian operations. She is brand new and ready to go to work.
Model Year
2020
Designer
AMS
Builder
AMS
Length
111' 7" - 34.00m
Beam
11
Draft
3.65
Hull Material
Steel
Deck Material
Steel
Engine Make
Cummins
Engine
2 x Cummins USA KTA50-M2
Horse Power
1600 x 2
Fuel Type
Diesel
Engine Hours
Zero
2nd Engine Hrs
Zero
Max Speed
13knts at 100$ MCR
Cruise Speed
10knts
Propulsion
2 x Fixed Pitch Propellers in Kort Nozzels
Thrusters
Veth VT-150 Tunnel Thruster 200kW @ 1500rpm/50Hz
Genset
2 x CCFJ235-Z-W-MYCM 235kw/415v/50Hz Cummins USA QSM11-DM engine
Fuel
320m/3
Water
30m3 (approx. )
Accommodation
11 crew; 3 x Single Cabins, 4 x 2 Man Cabins
Cabins
3 x Single Cabins, 4 x 2 Man Cabins
Berths
11
Galley
Full Galley
Refrigeration
Yes
Freezer
Yes
Stove
Yes
Water Maker
Aqua-Base YC4 (LPH : 240; PC : 2W)
Hotwater System
Yes
Shower
Yes
Toilet
Yes
Entertainment
Yes
Air Conditioning
Yes
Dinghy
Fast Rescue Craft to Class
Covers
Yes
Safety Gear
As per class and AMSA requiremetns
Bilge Pumps
35m3/hr @ 30m head Desmi Denmark
Life Raft
To Class AMSA
Epirb
1 x McMurdo Smartfind E5 406MHz
Life Jackets
To Class AMSA
Flares
To Class AMSA
Fire Protection
FFS 1/2 FiFi System; Pump 1540m3/hr with 2 x FFS600/150LB monitors
Electronics
SSB Radio 1 x JRC JSS-2150
VHF-FM Radio 2 x JRC JHS-770S
Inmarsat C (SSAS) 1 x JRC JUE-87
Inmarsat C (LRIT) 1 x JRC JUE-87
Navtex Receiver 1 x JRC NCR-333
Weather Fax 1 x JRC JAX-9B
GMDSS VHF Radio 4 x McMurdo R5 (2 way portable)
Radar 1 x JRC JMA-5212-6BB
Magnetic Compass 1 x Lilley & Gillie MK2000S
Echo Sounder 1 x JRC JFE-380-25
Speed Log 1 x JRC JLN-205MK2
AIS 1 x JRC JHS-183
Autopilot 1 x SIMRAD AP-70
DGPS 1 x JRC JLR-7500 DGPS
GPS Compass 1 x JRC JLR-21
PA System 1 x Hanshin HPA-7300
BNWAS 1 x Le Guardian 2025
Deck Gear
Anchor Windlass - Hydraulic Single drum, Double warp heads/gypsies; Pull: 18T @ 10m/min at 1st layer;Brake Holding: 80T (static, 1st layer).

Capstan - Hydraulic vertical capstan 5T @10m/min; dia. 400mm

Tugger Winch - Hydraulic Single Drum; Pull: 5T @ 10m/min at 1st layer; Brake Holding: 8T (static)

Anchort Handling / Towing Winch - Aft Hydrualic Waterfall Double Drums, Pull: 50T @ 15m/min (1st speed); 15T @ 30m/min (2nd speed); Brake Holding: 100T (static, 1st layer); Wire Capacity: 1000m x dia. 38mm

Shark Jaws - MKB Model: SJ400+TP400 100T WWL

Towing Pins - 85T WWL

Towing Hook - Mampaey 45T WLL Quick Release Disc

Deck Crane - HS Marine AKC 115/16.3 LHE4 Foldable Knuckle Type; Max 19.93T @ 4m; Min 4.06T @16.31m
