2025 STALWART MARINE WORK CAT 10.00 X 3.50 - New Boat Library

Description: Stalwart Marine Landing Craft 10 x 3.5 Work Boat Barge + A FrameGreat heavy-duty work platform in Survey 2C + 6 Pax
Marine grade Aluminium and fitted with 2 x 200hp OBM's
This vessel has been designed to be trailerable with the bridge folding down for transport
Specifications
Constructio n: Aluminium 5083-116/6061-T6
Survey: AMSA 2C 6 Pax
Plan Survey Approval: Included
Stability Report: Included
Impact Stability Analysis: Included
Construction Inspections: Included
LOA: 10.00 meters
WOA: 3.50 meters
Ramp Opening: 2.80 meters
Ramp Operation: Cable and Winch
Bridge: Raised 1950mm clearance
Deck: 5mm Plate - Self Draining with non-slip coating
Tie Bars under Gunwales: Included both sides full length
Toe Hold/Tie Down Points: Included both sides full length
Push Bars at Front
Vessel Load Limit: 3.5 tonnes
Engines: 2 x 200hp OMB
Fuel: 2 x 200lt
Work Benches x 2 under bridge 700W x 1050H x 1850L with 200mm return and wire tool wall
Battery: 4 x units high amperage with Isolators
A Frame Load: 1.50 tonne
A Frame Operation: Hydraulic Rams
A Frame Winch: 2 tonne (Hydraulic Recovery Type)
Hydraulic Power Pac: Included
Generator: Diesel 7 KVA (Silent 60db)
Deck wash: 2 x High Volume 240 volt (forward/aft)
Canopy: Included (Rubberised Tarp)
Slew Jib: Included x 2 with 2 x 1000kg 12 volt Recovery Winch (lifting 400kg)
Dive Ladder: 2 x pieces (removable)
Painting Above Waterline: Included colour and logo TBA
Painting Below Waterline: Included (International)
Deck Lighting: Included 2 x flood at ramp, 2 x flood at bridge
Navigation Lights: As per Survey
Bilge Pumps: As per Survey
Horn: As per Survey
Windscreen Wiper: As per Survey
