NEW Custom

21.7-meter excursion boat

1. Ship type and purpose

This vessel is a catamaran fibreglass pleasure boat operating in coastal waters. It sails under the condition of the restricted sea area with a wind force of level 7 and safe sea conditions. The hull material is fibreglass.

This vessel has satisfied all the requirements by NSCV and can be operated
in C water area with 98 pax and in E water area with 130 pax. If you want
to use this vessel to operate in the South Pacific region (such as some islands),
please contact Oceanic Design & Survey.
2. Technical specifications
Overall Length 21.70m
Length Waterline 19.32m
Beam 6.50m
Moulded Depth 2.40m
Designed Draft 1.05m
Design Speed 14.5kn
Design Occupants 98P
Crew 4P
Fuel Tank 2*1000L
Fresh-Water 1*1000L
Luggage 500kg
Total Tons / Units 93
Net tonnage 46
3. Main Equipment
Engine Power Yanmar 440X2
Gearbox China Advace HC138*2
Generator: China Sleeper 25KW/230V
4. Navigation Equipment
Standard Compass:
Steering Magnetic Compass:
Beidou Navigation Satellite:
Electronic Chart System:
Radar:
AIS:
5.
VHF Radiotelephone Station: 1
Lifeboat two-way VHF radio: F 2
NAVTEX: 1
SART: 1
Epirb: 1
Navigation signal lamp 1 Entireset
