South Coast 36 - Needs work


South Coast 36 Yacht - Fremantle

South Coast 36 sailing yacht needing completion. Most of the hard work has already been done, making this a solid project for someone wanting to finish and customise a capable offshore cruiser.

Background

At some stage in its life, the yacht had a substandard anchor locker / forward cabin bulkhead installation, which allowed water to leak into the bilge and keel area. This resulted in internal osmosis.

Over the past year, the vessel has been on the hard stand in Fremantle while the issue was addressed:

Affected areas were opened up and dried

The majority of keel patching has been completed

The keel (lead ingots set in concrete) has been injected with epoxy to fill any voids

Recent Work Completed

New forward lower bulkhead fabricated from marine plywood

New anchor locker floor fabricated from marine plywood

These will need final trim for fitment and laminating with fibreglass

Then top bulkhead fabricated. Marine ply and fiberglass with boat

Work Still Required

Final round of keel patching

Fitment and Fibreglassing of anchor locker and bulkhead areas

Fibreglass of bilge repairs

Putting it all back together, booms, sails, running rigging. All come with the boat.

Reason for Sale

Due to work commitments (I have been working upto 80 hours per week), I don't have the time to complete the project. The boat deserves to be finished properly and is being passed on to someone with the time and interest to do so. The boat is currently on hardstand at Fremantle Sailing Club. Will need to take over payment for hardstand or move it on. Currently leasing a pen at Fremantle, this possibly may be transferable.

Located in Fremantle, WA.

Region
Western Australia
Location
Perth Area Fremantle WA
Usage
Cruising
Launch Year
1989 approximate
Hull
Fibreglass/GRP
HIN
AU-WWA141562DJ6
Rego
GJ011
Rego Expiry
27/08/2026
Designer
Rudy Waalkens & Leif Bofeldt
Length
36' - 10.97m
Beam
3.35m - 10'8"
Draft
1.49m - 4'6"
Displacement
6.5t
Keel / Ballast
GRP - Lead ingots in concrete 2.64t ballast
Deck Material
GRP
Engine Make
Yanmar
Engine
4JH4AE - 2012 - 54hp Yanmar 4 cylinder diesel twin alternator
Number Engines
1
Horsepower
54
Fuel Type
Diesel
Engine Hours
< 1000
Max Speed
7kts
Cruise Speed
6kts
Propulsion
DF-107 Variprop 19" 4 blade variable pitch reversing propellor
Fuel
150 litre keel tank 80 litre day tank
Water
~125 litre bilge tank
Accommodation
Forward V berth 2 single bunks with loads of storage, Aft cabin has a double.
Cabins
Forward V berth 2 single bunks with loads of storage, Aft cabin has a double.
Berths
2 in V berth, 2 in Aft berth, 3 in saloon and nav station.
Galley
L shaped galley with twin sinks.
Refrigeration
Large fridge/freezer pus smaller fridge/freezer. Both have not been switched on for some years, require servicing.
Freezer
Large fridge/freezer plus smaller fridge/freezer. Both require servicing.
Stove
Broadwater 2 burner stove including grill and oven LPG
Hotwater System
40 litre Gem hot water system Powered by: Engine heat transfer 240 Volt shore power
Shower
In forward head
Toilet
Forward Head TMC Electric Macerator Toilet Black water tank or sea outlet Basin with shower hose built in Auto self draining shower floor Two upper storage cupboards Two lower storage cupboards Aft Head TMC Electric Macerator Toilet Wash Basin Two upper storage cupboards
Entertainment
Television
Kogan 19" 12/240 Volt Digital TV
Stereo
AM/FM Radio
Bluetooth and USB
Saloon and Cockpit speakers
Dinghy
Alicraft 255
Outboard
3.3hp Mercury Mariner, has not been in the water since rebuild. Requires new prop.
Ground Tackle
Muir 1600 Cougar Horizontal Windlass
Muir Windlass with gypsy and Rhode capstan, AutoAnchor 500C with chain counter and auto retrieval and forward and reverse deck switches.
Main anchor consists of 70m of brand new 10mm chain and 50m of 20mm nylon Rhode with a 25kg CQR anchor starboard
Backup anchor consits of 70mm of 10mm chain and 50mm of 20mm Rhode with 20kg Danforth anchor on port side
Spare anchors - 20kg Danforth and 20kg sand stored in port locker
Safety Gear
Life jackets, lanyards, jackets, EPIRB, drogue and lots of other gear.
Bilge Pumps
3 x electric auto 1 x manual gusher pump
Epirb
Yes
Life Jackets
Yes
Flares
Out of date
Fire Protection
2 x fire extinguishers
Electrics
Twin 80A alternators, 40A EPower charger for 3 banks, solar system on each battery bank, 400W wind generator
Electronics
Raymarine: Chart plotter, auto pilot, wind instruments, AIS, depth sounders and more.
Sail Inventory
3 head sails, main and mizzen.
Mast / Rigging
Fully battened Mizzen, reef points, running rigging to cockpit, lazyjacks and zip up boom bag
Fully battened Main, reef points, running rigging to cockpit, lazyjacks and zip up boom bag
No 1 Headsail on Furlex Furler
No 2 Headsail on Facnor furler
No 3 Headsail on Facnor furler

New stainless standing rigging in Sept 2023
Deck Gear
Main Winches
Port - Andersen 46ST 2 speed self tailing
Starboard - Andersen Electric / Manual 46ST 2 speed self tailing
Other winches
Andersen 28ST 2 speed self tailing
Remarks
This boat is has everything for long distance cruising. All setup for short crewing. All lines run to cockpit.
